Aventics R422102748, Einzelgrundplatte, Serie ES05 -Zoll

Activation: Electrically
Compressed air connection output: Base plate
Working pressure min.: 0 bar
Working pressure max: 8 bar
DC operating voltage: 24 V

Voltage tolerance DC: -15% / +10%
Manual override: without detent
Actuating control: Single Solenoid
Min. ambient temperature: 5 °C
Max. ambient temperature: 50 °C /tr>Min. medium temperature: 5 °C
Max. medium temperature: 50 °C
Medium: Compressed air
Max. particle size: 40 µm
Oil content of compressed air min.: 0 mg/m³
Oil content of compressed air max.: 5 mg/m³
Compressed air connection input: Ø 3/8
Compressed air connection, exhaust: Ø 3/8
Power consumption DC: 2 W
Duty cycle: 100 %
Protection class with connection: IP65
Housing material: Polyamide, Polyoxymethylene
