Dold HK3087N.16/004 DC24V, Interface module, sku: 0069865
Dold HK3087N.16/004 DC24V, Interface module, sku: 0069865
Regular price
€122,99
Regular price
Sale price
€122,99
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 01.01.2026
Couldn't load pickup availability
SKU: SKU:0069865
The interface module HK 3087N has forcibly guided contacts. Therefore it can be used to safely separate control and load circuits as well as to reinforce contacts of safety devices. The interface module has a strong isolation between monitoring and load contact and is designed for high thermal current.
| Width: | 22,5 mm |
| Nominal voltage: | DC |
| Thermal current Ith max.: | 25 A |
| Enclosure design: | Switch cabinet |
| Connection: | Screw terminals |
| Output contacts max.: | 1 NO contact, 1 NC contact |
| Type: | HK 3087N |
- According to IEC/EN 61810-1, IEC 60664-1,
- With forcibly guided contacts according to IEC 61810-3
- Models with soldered in PCB safety relay
- With polarity protected diode
- Optionally with free-wheeling diode across relay coil
- With LED indicator
- For DIN rail mounting according IEC/EN 60715
- Clearance and creepage distance between NC and NO contact > 10 mm
- Width 22,5 mm
