Dold
Dold UG3096.63/800 DC24V, Interface module, sku: 0065530
Dold UG3096.63/800 DC24V, Interface module, sku: 0065530
Regular price
€144,23
Regular price
Sale price
€144,23
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 01.01.2026
Couldn't load pickup availability
SKU: SKU:0065530
Interfacing between control and load circuitsContact multiplication and reinforcementSeparate switching of several current circuits, e. g. with- Machines and plants,- Energy production and transport
| Width: | 22,5 mm |
| Nominal voltage: | DC |
| Thermal current Ith max.: | 6 A |
| Enclosure design: | Switch cabinet |
| Connection: | Pluggable screw terminals |
| Output contacts max.: | 4 NO contacts, 4 NC contacts |
| Type: | UG 3096 |
- With forcibly guided contacts according to IEC 61810-3
- UG 3096: 8 output contacts
UH 3096: 16 output contacts - As option with gold plated contacts to switch low loads
- As option with contacts connected in series to switch high DC-loads
- As option with pluggable terminal blocks for easy exchange of devices
- With screw terminals - UG 3096: Width 22.5 mm
UH 3096: Width 45 mm
