Mains buffering time (nominal voltage 24 V DC) [ms]
10
Closed-circuit current [mA]
12
Number of channels
2
Nominal current [A]
1...10
Nominal current (Fail Safe Element) [A]
10
Outputs
Load capacitance, total [mF]
20
Operating conditions
Ambient temperature [°C]
-25...60
Storage temperature [°C]
-40...70
Protection
IP 20;(on the front)
Pollution degree
2
Tests / approvals
EMC
EN 61000-6-3
radiation of interference
EN 61000-6-2
immunity
Weight [g]
73.5
Dimensions [mm]
80 x 12.5 x 98
Displays / operating elements
Display
status
2 x LED, red / green / orange
Operating elements
2 x
pushbutton
Electrical connection
Connection
push-in terminals:
Diagrams and graphs
output characteristics
time-current characteristics
