128 kBytes offer sufficient memory capacity for relevant data and histories. Process-relevant information is provided locally. Digital type label: simple registration of interchangeable components to the PLC
Application
data storage via IO-Link
Operating voltage [V]
18...30 DC
Current consumption [mA]
< 50
Protection class
III
Memory size [bit]
1042432
Memory type
FRAM
Max. read cycles
unlimited
Max. write cycles
unlimited
Interfaces
Communication interface
IO-Link
Transmission type
COM3 (230,4 kBaud)
IO-Link revision
1.1
SDCI standard
IEC 61131-9
Profiles
Smart Sensor: Device Identification
SIO mode
no
Required master port type
A
Supported DeviceIDs
Type of operation
DeviceID
default
1423
Operating conditions
Ambient temperature [°C]
-20...60
Storage temperature [°C]
-25...80
Protection
IP 67; IP 69K
Tests / approvals
EMC
EN IEC 61000-6-2
EN IEC 61000-6-4
Shock resistance
EN 60068-2-27
40 g 6 ms / repetitive
EN 60068-2-27
50 g 11 ms / not repetitive
Vibration resistance
EN 60068-2-6
20 g 10...2000 Hz
UL approval
Ta
-20...60 °C
Enclosure type
Type 1
power supply
Limited Voltage/Current
File number UL
E205959
Weight [g]
59.8
Housing
rectangular
Mounting
non-flush mountable
Dimensions [mm]
20 x 7 x 48
Materials
PBT; TPU; stainless steel
Displays / operating elements
Display
operation
1 x LED, green
Memory access
1 x LED, yellow
Pack quantity
1 pcs.
Electrical connection
Connection
Cable: 1 m, PUR; 3 x 0.14 mm²
Connection
Connector: 1 x M12; coding: A
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — DSU100-00 — 31.05.2021 —
