IFM E12732 - Connecting cable with plug ASTGH080VAS0010G08

High protection rating for the requirements of the food and beverage industry.
Permanent, reliable sealing even when mounted without tools.
Wide operating temperature range.
Good electromagnetic compatibility thanks to shielded cable.
Angled type for use where space is restricted

Special feature	Screened cable

Operating voltage [V]	< 30 AC / < 36 DC
Protection class	III

Operating conditions

Ambient temperature [°C]	-25...80
Protection	IP 67

Weight [g]	678.9
Dimensions [mm]	26.5 x 15 x 38.5
Materials	PVC
Moulded-body material	PVC
Material nut	stainless steel

Pack quantity	1 pcs.

Electrical connection

	Cable: 10 m, PVC, orange, Ø 6.6 mm, shielded; 8 x 0.25 mm² (14 x Ø 0.15 mm )

Electrical connection - plug

Connection	Connector: 1 x M12, straight; coding: A; Moulded body: PVC; Locking: stainless steel; Tightening torque: 0.7...0.9 Nm; Shielded connection cable: screen connected

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E12732-00 — 23.07.2020 —
