IFM E40114 - Screw-in adapter for process sensors ADAPT /SI/9/ /G1/2/

For the installation of flow and temperature sensors in containers and pipes.
Easy, quick and secure mounting.
Suitable for liquids and gases.
High permissible overload pressure rating.
Robust titanium design for use in aggressive media

Application	for industrial applications
Media	liquids and gases
Pressure rating [bar]	30

Tests / approvals

Pressure Equipment Directive	A possible classification to PED depends on the application and has to be carried out by the user / operator.
Safety instructions	The compatibility between medium andproduct material has to be checked in all applications.

Weight [g]	32.5
Dimensions [mm]	M18 x 1.5
Thread designation	M18 x 1.5
Materials	titanium (3.7035)
Sensor connection	M18 x 1,5
Process connection	threaded connection G 1/2
Insertion depth [mm]	21;(measuring probe SID, SFD, TN)

Accessories

Items supplied	sealings: 1, PTFE

Remarks	In applications >30 bar and ≤300 bar only use with a U-Seal sealing ring.
Pack quantity	1 pcs.

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E40114-00 — 10.11.2014 —
