IFM E40160 - Clamp fitting for process sensors CLAMP ADAPTER R1/2

For the installation of flow sensors in pipes.
Easy, quick and secure mounting.
Easy adjustment of the immersion depth of the sensor.
Very high, reliable overload pressure rating.
Robust stainless steel design for use in harsh industrial environments

Design	for flow sensors Ø 10 mm
Application	for industrial applications
Installation	Clamp fitting
Media	liquids and gases
Pressure rating [bar]	300

Operating conditions

Ambient temperature [°C]	-25...80

Tests / approvals

Pressure Equipment Directive	A possible classification to PED depends on the application and has to be carried out by the user / operator.
Safety instructions	The compatibility between medium andproduct material has to be checked in all applications.

Weight [g]	80
Materials	stainless steel
Sensor connection	Ø 10 mm
Process connection	threaded connection R 1/2

Pack quantity	1 pcs.

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E40160-00 — 11.11.2014 —
