IFM E80347 - RFID tag ID-TAG/M5x16,5/06

RFID tag 13.56 MHz - ISO15693.
Reliable coding of workpiece carriers and products.
Suitable for installation with plastic carrier

Application	coding of workpiece carriers in routing conveyors
Operating temperature (active) [°C]	-25...85
Peak temperature (passive) [°C]	90

Operating frequency [MHz]	13,56
Memory size [bit]	896
Memory type	EEPROM
Chip type	Vigo
Number of blocks	28
Block size [Byte]	4
Unique Identification Number (UID) [Byte]	8
RFID standard	ISO 15693
Max. read cycles	unlimited
Max. write cycles	100000

Operating conditions

Ambient temperature [°C]	-25...85
Storage temperature [°C]	-40...90
Protection	IP 67

Tests / approvals

Shock resistance	DIN IEC 68-2-29 30 g 18 ms
Vibration resistance	DIN IEC 68-2-6 6 g 14...200 Hz
Radio approval	ISO 15693

Weight [g]	4.4
Housing	threaded type
Type of mounting	installation on non-metal materials;(screw fastening ; sticking to a surface)
Dimensions [mm]	M5 / L = 16.5
Thread designation	M5
Materials	PA black

Pack quantity	10 pcs.
