ifm Electronic
Regular price
€83,20
Regular price
Sale price
€83,20
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 31.12.2025
Couldn't load pickup availability
SKU: SKU:E80407
| Operating temperature (active) [°C] |
-30...50 |
| Operating frequency [MHz] |
13,56 |
| Memory size [bit] |
896 |
| Memory type |
EEPROM |
| Chip type |
ICODE SLIX |
| Number of blocks |
28 |
| Block size [Byte] |
4 |
| Unique Identification Number (UID) [Byte] |
8 |
| RFID standard |
ISO 15693 |
| Max. read cycles |
unlimited |
| Max. write cycles |
100000 |
Operating conditions
| Ambient temperature [°C] |
-30...50 |
| Protection |
IP 67 |
Tests / approvals
| Shock resistance |
| DIN IEC 68-2-27 |
40 g 18 ms |
|
| Vibration resistance |
| DIN IEC 68-2-6 |
10 g 10...2000 Hz |
|
| Radio approval |
ISO 15693 |
| Weight [g] |
53.5 |
| Dimensions [mm] |
54 x 86 x 1 |
| Materials |
PVC |
Other data
Reading distance when mounted on non-metal (mm)
| ANT410 / DTI410 |
22 |
| ANT411 / DTI411 |
35 |
| ANT420 / DTI420 / DTM424 / DTI424 / DTM426 |
20 |
| ANT421 / DTI421 / DTM425 / DTI425 / DTM427 |
65 |
| ANT430 / DTI430 / DTM434 / DTI434 / DTM436 |
50 |
| ANT431 / DTI431 / DTM435 / DTI435 / DTM437 |
85 |
| ANT513 / DTI513 / DTC510 |
120 |
| ANT515 / DTI515 / ANT516 / DTI516 |
50 |
| ANT600 / DTI600 |
230 |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E80407-00 —
