Resistant to oils and coolants. Permanent, reliable sealing even when mounted without tools. Mechanical end stop to protect the O-ring from destruction. Robust housing for use in harsh industrial environments. High shock and vibration resistance
Special feature
Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability
Free from silicone
yes
Operating voltage [V]
< 30 DC;("supply class 2" to cULus)
Protection class
II
Max. current load per module/slot [A]
4
Max. current load total [A]
12
Operating conditions
Ambient temperature [°C]
-25...80
Ambient temperature (moving) [°C]
-5...60
Protection
IP 67; IP 68
Tests / approvals
UL approval
Enclosure type
Type 1
Weight [g]
906.5
Dimensions [mm]
22 x 54 x 127
Materials
PA
Moulded-body material
PA
Number of ports splitter box
8
Connector type
M12
Drag chain suitability
yes
Drag chain suitability
bending radius for flexible use
min. 10 x cable diameter
travel speed
max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s²
bending cycles
> 2 Mio.
torsional strain
± 30 °/m
Accessories
Items supplied
Protective caps: 2
labels: 8
Pack quantity
1 pcs.
Electrical connection
Cable: 5 m, PUR, Halogen-free, black, Ø 9.7 mm; 16 x 0.34 mm² (43 x Ø 0.1 mm ) + 3 x 0.75 mm² (95 x Ø 0.1 mm )
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — EBC022-01 — 20.09.2023 —
