Weld-slag resistant PUR cable with drag chain suitability. Nut with special weld-slag resistant coating. High protection rating for the requirements of harsh industrial environments. Vibration and shock resistant thanks to coupling ring with locking mechanism. Mechanical end stop to protect the O-ring from destruction
Special feature
Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability
Application
welding applications
Free from silicone
yes
Operating voltage [V]
10...36 DC
Protection class
II
Max. current load total [A]
4
Outputs
Electrical design
PNP
Operating conditions
Ambient temperature [°C]
-25...90
Note on ambient temperature
cULus: ...75 °C
Ambient temperature (moving) [°C]
-25...90
Note on ambient temperature (moving)
cULus: ...75 °C
Protection
IP 65; IP 67; IP 68; IP 69K
Weight [g]
70.3
Moulded-body material
TPU
Material nut
brass, anti-spatter
Sealing material
FKM
Number of ports splitter box
2
Drag chain suitability
yes
Drag chain suitability
bending radius for flexible use
min. 10 x cable diameter
travel speed
max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s²
bending cycles
> 2 Mio.
torsional strain
± 180 °/m
Displays / operating elements
Display
switching status
2 x LED, yellow
operation
2 x LED, green
Remarks
with 4 label holders 30 mm long
Pack quantity
1 pcs.
Electrical connection
Cable: 0.3 m, PUR, Halogen-free, grey, Ø 4.9 mm; not irradiated (can be recycled); 3 x 0.34 mm² (42 x Ø 0.1 mm )
