IFM IB5169 - Inductive sensor IB-2020-FRKG/US-104-IRF

Output function normally open / normally closed programmable.
Two-wire technology.
With robust M12 connector.
Smooth plastic housing to protect against deposits.
PBT housing resistant against pickling solutions

Electrical design	PNP/NPN
Output function	normally open / normally closed;(selectable)
Sensing range [mm]	20
Housing	cylindrical
Dimensions [mm]	Ø 34 / L = 95

Special feature	Gold-plated contacts

Operating voltage [V]	10...36 DC
Protection class	II
Reverse polarity protection	yes

Outputs

Electrical design	PNP/NPN
Output function	normally open / normally closed;(selectable)
Max. voltage drop switching output DC [V]	4.6
Minimum load current [mA]	4
Max. leakage current [mA]	1
Permanent current rating of switching output DC [mA]	250
Switching frequency DC [Hz]	200
Short-circuit protection	yes
Overload protection	yes

Detection zone

Sensing range [mm]	20
Real sensing range Sr [mm]	20 ± 10 %
Operating distance [mm]	0...16.2

Accuracy / deviations

Correction factor	steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3
Hysteresis [% of Sr]	1...15
Switch point drift [% of Sr]	-10...10

Operating conditions

Ambient temperature [°C]	-25...70
Protection	IP 67

Tests / approvals

EMC	EN 60947-5-2
MTTF [years]	1941

Weight [g]	226
Housing	cylindrical
Mounting	non-flush mountable
Dimensions [mm]	Ø 34 / L = 95
Materials	housing: PBT; sensing face: PBT orange; clamp: PBT black

Displays / operating elements

Display	switching status 4 x 90° LED, yellow

Accessories

Items supplied	Mounting clamps: 1

Pack quantity	1 pcs.

Electrical connection - plug

	Connector: 1 x M12; coding: A; Locking: brass, anti-spatter; Contacts: gold-plated
