IFM JAT201 - Diffuse reflection sensor AFK3050BBPKG/M/V4A/US-104

High ingress protection for use in the food and beverage industry.
Resistant to high-pressure cleaning with aggressive cleaning agents.
Long sensing range for high uptime.
Excellent price/performance ratio.
Robust stainless steel housing for use in harsh industrial environments

Dimensions [mm]	M12 x 1 / L = 63

Operating conditions

Ambient temperature [°C]	0...100
Protection	IP 65; IP 67; IP 68; IP 69K

Tests / approvals

EMC	EN 61000-4-2 ESD 4 kV CD / 8 kV AD EN 61000-4-3 HF radiated 10 V/m (80...1000 MHz) EN 61000-4-4 Burst 2 kV EN 61000-4-5 Surge 0,5 kV EN 61000-4-6 HF conducted 10 V (0,15...80 MHz) EN 55011 class B
MTTF [years]	1048

Weight [g]	84.5
Dimensions [mm]	M12 x 1 / L = 63
Thread designation	M12 x 1

Pack quantity	1 pcs.

Electrical connection - plug

	Connector: 1 x M12; coding: A
