Safe switch point also in case of mechanical tolerances. Long sensing range even through non-magnetisable metals. Temperature-stable and reproducible switch point. Clearly visible indication of the switching status. High impact, shock and vibration resistance
Electrical design
PNP
Output function
normally open
Sensing range [mm]
60;(referred to magnet M 4.0)
Housing
threaded type
Dimensions [mm]
M12 x 1 / L = 60
Special feature
Gold-plated contacts
Pressure rating [bar]
100
Operating voltage [V]
10...30 DC
Current consumption [mA]
< 10
Protection class
III
Reverse polarity protection
yes
Outputs
Electrical design
PNP
Output function
normally open
Max. voltage drop switching output DC [V]
2.5
Permanent current rating of switching output DC [mA]
200
Switching frequency DC [Hz]
5000
Short-circuit protection
yes
Type of short-circuit protection
pulsed
Overload protection
yes
Detection zone
Sensing range [mm]
60;(referred to magnet M 4.0)
Response sensitivity [mT]
1.2
Accuracy / deviations
Hysteresis [% of Sr]
1...10
Operating conditions
Ambient temperature [°C]
-40...75
Storage temperature [°C]
-40...75
Protection
IP 65; IP 67
Tests / approvals
EMC
EN 61000-4-2 ESD
4 kV CD / 8 kV AD
EN 61000-4-3 HF radiated
10 V/m
EN 61000-4-4 Burst
2 kV
EN 61000-4-5 Surge
0,5 kV line to line, Ri: 2 Ohm
EN 61000-4-6 HF conducted
10 V
EN 55011
class B
DIN ISO 11452-2
100 V/m
MTTF [years]
1401
Weight [g]
28.5
Housing
threaded type
Dimensions [mm]
M12 x 1 / L = 60
Thread designation
M12 x 1
Materials
housing: stainless steel; sensing face: stainless steel; LED window: PA
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — MFS212-00 — 13.04.2023 —
