Permanent current rating of switching output DC [mA]
100
Switching frequency DC [Hz]
10000
Short-circuit protection
yes
Type of short-circuit protection
pulsed
Overload protection
yes
Detection zone
Response sensitivity [mT]
2.8
Travel speed [m/s]
> 10
Accuracy / deviations
Hysteresis [mm]
< 1.5
Repeatability [mm]
< 0.2
Operating conditions
Ambient temperature [°C]
-25...85
Protection
IP 65; IP 67
Tests / approvals
EMC
EN 61000-4-2 ESD
- CD / 8 kV AD
EN 61000-4-3 HF radiated
10 V/m
EN 61000-4-4 Burst
2 kV
EN 61000-4-6 HF conducted
10 V
EN 55011
class B
MTTF [years]
3694
UL approval
Ta
-25...75 °C
Enclosure type
Type 1
power supply
Limited Voltage/Current (Marking Class 2)
UL Approval no.
C003
File number UL
E174191
Weight [g]
29.4
Mounting
flush mountable
Type of mounting
fastening clamp with combined slot / hexagon socket, width across flats 1.5
Cylinder type
T-slot cylinders
Dimensions [mm]
25 x 5 x 6.5
Materials
housing: PA; fastening clamp: stainless steel
Displays / operating elements
Display
switching status
1 x LED, yellow
Accessories
Items supplied
rubber placeholder: 1
Cable clip: 1
Pack quantity
1 pcs.
Electrical connection - plug
Connection
Cable: 1 m, PUR; cross-linked
Connection
Connector: 1 x M12; coding: A; Locking: knurled nut, rotatable
