Precise detection of small parts. Simple alignment due to visible laser light spot. Very long range. Sensitivity adjustable via teach buttons. Programmable light-on/dark-on mode
Type of light
red light
Laser protection class
1
Housing
rectangular
Special feature
polarisation filter
Function principle
Retro-reflective sensor
Operating voltage [V]
10...36 DC
Current consumption [mA]
15
Protection class
II
Reverse polarity protection
yes
Type of light
red light
Wave length [nm]
655
Outputs
Electrical design
PNP
Output function
light-on/dark-on mode;(programmable)
Max. voltage drop switching output DC [V]
2.5
Permanent current rating of switching output DC [mA]
200
Switching frequency DC [Hz]
2000
Short-circuit protection
yes
Type of short-circuit protection
pulsed
Overload protection
yes
Detection zone
Range referred to prismatic reflector [m]
15;(Prismatic reflector Ø 80 E20005)
Range adjustable
yes
Diameter of the smallest detectable object [mm]
3;(1 m; 15 m: 20)
Max. light spot diameter [mm]
40
Light spot dimensions refer to
at maximum range
Polarisation filter available
yes
Operating conditions
Ambient temperature [°C]
-10...60
Protection
IP 67
Tests / approvals
EMC
EN 60947-5-2
Laser protection class
1
Notes on laser protection
Caution:
laser light
laser class:
1
EN / IEC60825-1:2007
EN / IEC60825-1:2014
Complies with 21 CFR 1040 except for deviations pursuant to Laser Notice No. 50, dated June 2007.
operating voltage "supply class 2" according to cULus
Pack quantity
1 pcs.
Electrical connection
Connection
Connector: 1 x M12; coding: A
