IFM OG5129 - Through-beam sensor transmitter OGS-OOKG/US/90°

Particularly space-saving design with light emission on the side.
For use where space is restricted.
Ready for operation immediately thanks to fixed setting.
Robust housing for use in harsh industrial environments.
Very long range

Type of light	red light
Housing	threaded type

Function principle	Through-beam sensor

Operating voltage [V]	10...30 DC;("supply class 2" to cULus)
Current consumption [mA]	< 19
Protection class	II
Reverse polarity protection	yes
Type of light	red light
Wave length [nm]	660

Detection zone

Transmitter / receiver	transmitter
Range [m]	< 9
Range adjustable	no
Max. light spot diameter [mm]	3000
Light spot dimensions refer to	at maximum range

Operating conditions

Ambient temperature [°C]	-25...60
Protection	IP 68

Tests / approvals

EMC	EN 60947-5-2 EN 55011 class B
MTTF [years]	1714

Weight [g]	58
Housing	threaded type
Dimensions [mm]	M18 x 1 / L = 59.3
Thread designation	M18 x 1
Materials	stainless steel; ABS
Lens material	PMMA

Displays / operating elements

Display	operation 1 x LED, green

Accessories

Items supplied	Nuts: 2 lock washers: 2

Pack quantity	1 pcs.

Electrical connection

Connection	Connector: 1 x M12; coding: A

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — OG5129-00 — 13.04.2023 —
