IFM SV3050 - Vortex flow meter SVM12XXXD0KG/US-100

Reliable detection of flow in pipes.
Precise linearized analogue output.
Suitable for water and water-based media

Number of inputs and outputs	Number of analogue outputs: 1
Measuring range	0.5...10 l/min 0.074...1.474 m/s
Process connection	threaded connection G 1/2 DN6

Special feature	Gold-plated contacts
Application	for industrial applications
Installation	connection to pipe by means of an adapter
Media	water; glycol solutions; coolants
Medium temperature [°C]	-40...100
Min. bursting pressure [bar]	25
Min. bursting pressure [MPa]	2.5
Pressure rating [bar]	12
Pressure rating [MPa]	1.2
Note on pressure rating	up to 40 °C

Operating voltage [V]	8...33 DC
Min. insulation resistance [MΩ]	100;(500 V DC)
Protection class	III
Power-on delay time [s]	< 2

Inputs / outputs

Number of inputs and outputs	Number of analogue outputs: 1

Outputs

Total number of outputs	1
Output signal	analogue signal
Number of analogue outputs	1
Analogue current output [mA]	4...20; (Q [l/min] = 0,625 x (I - 4 mA))
Max. load [Ω]	< (Ub - 8 V) / 20 mA; Ub = 24 V: 800

Measuring/setting range

Measuring range	0.5...10 l/min 0.074...1.474 m/s

Accuracy / deviations

Accuracy (in the measuring range)	Q < 50 % MEW: < 1 % MEW / Q > 50 % MEW: < 2 % MW;(water)
Repeatability	0,2;(% of the final value)

Response times

Response time [s]	0.5

Operating conditions

Ambient temperature [°C]	-15...85
Storage temperature [°C]	-30...85
Protection	IP 65
Cavitation	P(absolute) discharge / P(difference) > 5.5 to avoid cavitation

Tests / approvals

EMC	EN 61326-2-3
Shock resistance	DIN EN 60068-2-27 30 g (11 ms)
Vibration resistance	DIN EN 60068-2-6 with water / 10...61 Hz 1 mm with water / 61...2000 Hz 2 g
MTTF [years]	380
Pressure Equipment Directive	Sound engineering practice; can be used for group 2 fluids; group 1 fluids on request

Weight [g]	67
Materials	PA 6T
Materials (wetted parts)	ETFE; PA 6T; FKM
Tightening torque [Nm]	12
Process connection	threaded connection G 1/2 DN6

Remarks	MW = measured value MEW = Final value of the measuring range
Pack quantity	1 pcs.

Electrical connection

Connection	Connector: 1 x M12; coding: A; Contacts: gold-plated

Diagrams and graphs

Pressure loss	dP Pressure loss Q volumetric flow quantity

min. life 10 years referred to flow and high medium temperatures

pressure rating (bar)
