Also suitable for small nominal pipe diameters and confined spaces. Very short response time < 0.25 / < 1s. Free 3-point calibration certificate available online
Number of inputs and outputs
Number of analogue outputs: 1
Measuring range [°C]
-50...200
Process connection
threaded connection M12 x 1,5 sealing cone
Installation length EL [mm]
17
Measuring element
1 x Pt 1000;(to DIN EN 60751, class A)
Media
liquids and gases
Pressure rating [bar]
100
Vacuum resistance [mbar]
-1000
Operating voltage [V]
18...32 DC;("supply class 2" to cULus)
Current consumption [mA]
< 50
Protection class
III
Reverse polarity protection
yes
Power-on delay time [s]
2
Inputs / outputs
Number of inputs and outputs
Number of analogue outputs: 1
Outputs
Total number of outputs
1
Output signal
analogue signal; IO-Link;(configurable)
Number of analogue outputs
1
Analogue current output [mA]
4...20
Max. load [Ω]
250;((18...19 V); 19...32 V: 300 Ω)
Short-circuit protection
yes
Overload protection
yes
Measuring/setting range
Measuring range [°C]
-50...200
Factory setting
0...100 °C
Resolution
Resolution of analogue output [K]
0.04
Accuracy / deviations
Precision analogue output [K]
± 0,3 + (± 0,1 % MS)
Temperature coefficient [% of the span / 10 K]
0,1;(in case of deviation from the reference condition 25 ± 5 °C)
Response times
Dynamic response T05 / T09 [s]
< 0,25 / < 1
Interfaces
Communication interface
IO-Link
Transmission type
COM2 (38,4 kBaud)
IO-Link revision
1.1
Operating conditions
Ambient temperature [°C]
-25...80
Note on ambient temperature
at medium temperature: < 160 °C
-25...60 °C
at medium temperature: < 200 °C
Storage temperature [°C]
-40...100
Protection
IP 67; IP 68; IP 69K
Tests / approvals
EMC
DIN EN 61000-6-2
DIN EN 61000-6-3
Shock resistance
DIN IEC 68-2-27
50 g (11 ms)
Vibration resistance
DIN IEC 68-2-6
10 g (10...2000 Hz)
MTTF [years]
334
Note on approval
factory certificate available as download at www.factory-certificate.ifm
UL approval
UL Approval no.
K002
Weight [g]
112
Materials
stainless steel (1.4404 / 316L); PEI; FKM
Materials (wetted parts)
stainless steel (1.4404 / 316L) electropolished
Tightening torque [Nm]
20
Process connection
threaded connection M12 x 1,5 sealing cone
Surface characteristics Ra/Rz of the wetted parts
Ra: < 0.8
Probe diameter [mm]
3
Installation length EL [mm]
17
Remarks
MS = set measuring span
The values for accuracy apply to flowing water.
Pack quantity
1 pcs.
Electrical connection
Connection
Connector: 1 x M12; coding: A
