Schmersal AZM 415-02/02ZPKTEI 24VAC/DC Sicherheitszuhaltungen, sku: 101186832

Schmersal AZM 415-02/02ZPKTEI 24VAC/DC Sicherheitszuhaltungen, sku: 101186832

€875,36
€875,36
Sale Sold out
Taxes included.

📦 Ready for dispatch: 02.12.2025

SKU: 101186832

  • Metallgehäuse
  • Fehlschließsichere Zuhaltung
  • robuste Ausführung
  • hohe Lebensdauer
  • 2 Leitungseinführungen M 20 x 1.5
  • Schraubklemmenanschluss
  • Product type description: AZM 415-02/02ZPKTEI 24VAC/DC
  • Article number (order number): 101186832
  • EAN (European Article Number): 4030661334462
  • eCl@ss number, version 12.0: 27-27-26-03
  • eCl@ss number, version 11.0: 27-27-26-03
  • eCl@ss number, version 9.0: 27-27-26-03
  • ETIM number, version 7.0: EC002593
  • ETIM number, version 6.0: EC002593
  • Certificates: BG, cULus, CCC
  • Standards: BG-GS-ET-19, EN IEC 60947-5-1
  • Working principle: electromechanical
  • Enclosure material: Aluminium
  • Enclosure coating material: painted
  • Gross weight: 1,050 g
  • Power to unlock: Yes
  • Emergency exit: Yes
  • Number of actuating directions: 1
  • Number of safety contacts: 4
  • Number of guard doors: 1
  • Safety classification: 1
  • Standards: EN ISO 13849-1
  • Mission time: 20 Year(s)
  • B10D Normally-closed contact (NC): 2,000,000 Operations
  • Mechanical life, minimum: 1,000,000 Operations
  • Holding force FZh in accordance with EN ISO 14119: 3,500 N
  • Latching force, minimum: 150 N
  • Latching force, maximum: 400 N
  • Positive break travel: 5 mm
  • Positive break force, minimum: 15 N
  • Actuating speed, maximum: 0.2 m/s
  • Termination: Screw terminals M20 x 1.5
  • Cable section, minimum: 2 x 0.75 mm²
  • Cable section, maximum: 2 x 2.5 mm²
  • Note (Cable section): All indications including the conductor ferrules.
  • Length of sensor: 46.5 mm
  • Width of sensor: 152 mm
  • Height of sensor: 100 mm
  • Degree of protection: IP67
  • Ambient temperature: -25 ... +50 °C
  • Rated insulation voltage Ui: 250 VAC
  • Rated impulse withstand voltage Uimp: 4 kV
  • Thermal test current: 6 A
  • Rated control voltage: 24 VAC/DC
  • Utilisation category AC-15: 230 VAC
  • Utilisation category AC-15: 4 A
  • Utilisation category DC-13: 24 VDC
  • Utilisation category DC-13: 1 A
  • Electrical power consumption, maximum: 10 W
  • Switching element: Opener (NC)
  • Switching principle: Slow action
  • Material of the contacts, electrical: Silver
  • Note (applications): sliding safety guard, hinged safety guard
  • Note (Emergency exit): using latched pushbutton, The emergency exit is used where an intervention in an already locked hazardous area is required, Emergency exit by pressing the red push button, Resetting by pulling on the latched button, In removed condition, the guard device is protected against unintentional closing
