Schmersal MD 441-11Y-T-M20 Mittellast-Positionsschalter, sku: 101164827

Schmersal MD 441-11Y-T-M20 Mittellast-Positionsschalter, sku: 101164827

€421,02
€421,02
Sale Sold out
Taxes included.

📦 Ready for dispatch: 19.12.2025

SKU: 101164827

  • Metallgehäuse
  • Betätigungsvorsatz nachträglich um 4 x 90º umsetzbar
  • Betätiger stufenlos um 360º einstellbar
  • 2 Kontakte
  • Betätiger ist um 180º auf Welle umsetzbar
  • in temperaturfester Ausführung ist die Rolle in 2 verschiedenen Positionen auf der Welle montierbar
  • 106 mm x 99 mm x 63 mm (Grundgerät)
  • Schutzart IP65
  • Product type description: MD 441-11Y-T-M20
  • Article number (order number): 101164827
  • EAN (European Article Number): 4030661206967
  • eCl@ss number, version 12.0: 27-27-06-01
  • eCl@ss number, version 11.0: 27-27-06-01
  • eCl@ss number, version 9.0: 27-27-06-01
  • ETIM number, version 7.0: EC000030
  • ETIM number, version 6.0: EC000030
  • Certificates: CCC
  • Standards: EN IEC 60947-5-1
  • Working principle: mechanical
  • Slide form: Castor
  • Enclosure material: Grey cast iron, galvanised
  • Enclosure coating material: painted
  • Gross weight: 1,695 g
  • Number of normally closed (NC): 1
  • Number of normally open (NO): 1
  • B10D Normally-closed contact (NC): 2,000,000 Operations
  • Actuating element: Roller lever
  • Roller material: Brass
  • Mechanical life, minimum: 5,000,000 Operations
  • Actuating angle, from left of switch axis: 30 °
  • Actuating angle, from right of switch axis: 30 °
  • Contact opening: 2 x 2.5 mm
  • Actuating speed, minimum: 1 mm/min
  • Actuating speed, maximum: 3 m/s
  • Note (Actuating speed): Actuating speed with vertical actuating angle to switch axis
  • Termination: Screw terminals M20 x 1.5
  • Cable section, minimum: 1.5 mm²
  • Cable section, maximum: 2.5 mm²
  • Note (Cable section): All indications including the conductor ferrules.
  • Wire cross-section: 13 AWG
  • Length of sensor: 63 mm
  • Width of sensor: 106 mm
  • Height of sensor: 237 mm
  • Width of Castor: 9 mm
  • Diameter of Castor: 36 mm
  • Degree of protection: IP65
  • Ambient temperature: -40 ... +200 °C
  • Rated insulation voltage Ui: 250 VAC
  • Rated impulse withstand voltage Uimp: 4 kV
  • Thermal test current: 16 A
  • Utilisation category AC-15: 250 VAC
  • Utilisation category AC-15: 4 A
  • Switching element: NO contact, NC contact
  • Note (Switching element): galvanically separated contact bridges
  • Switching principle: Snap action
  • Bounce duration, maximum: 5 ms
  • Switchover time, maximum: 35 ms
  • Material of the contacts, electrical: Silver
