Schmersal T. 441-11Y-M20-243 Bandschieflaufschalter, sku: 101170427

Schmersal T. 441-11Y-M20-243 Bandschieflaufschalter, sku: 101170427

€445,69
€445,69
Sale Sold out
Taxes included.

📦 Ready for dispatch: 02.12.2025

SKU: 101170427

  • 2 Leitungseinführungen M20
  • Metallgehäuse
  • 2 Kontakte
  • 106 mm x 99 mm x 63 mm ( Grundgerät)
  • für schweren Betrieb geeignet
  • Product type description: T. 441-11Y-M20-243
  • Article number (order number): 101170427
  • EAN (European Article Number): 4030661297651
  • eCl@ss number, version 12.0: 27-27-06-01
  • eCl@ss number, version 11.0: 27-27-06-01
  • eCl@ss number, version 9.0: 27-27-06-01
  • ETIM number, version 7.0: EC000030
  • ETIM number, version 6.0: EC000030
  • Certificates: CCC
  • Standards: EN IEC 60947-5-1
  • Working principle: mechanical
  • Housing material: Grey cast iron, galvanised
  • Housing coating material: painted
  • Gross weight: 1,821 g
  • Number of normally closed (NC): 1
  • Number of normally open (NO): 1
  • B10DNormally-closed contact (NC): 2,000,000 Operations
  • Mechanical life, minimum: 10,000,000 Operations
  • Contact opening: 2 x 6 mm
  • Actuation direction: each time 60° right-hand side and left-hand side rotation
  • Termination: Screw terminals M20 x 1.5
  • Cable section, minimum: 1.5 mm²
  • Cable section, maximum: 2.5 mm²
  • Length of sensor: 63 mm
  • Width of sensor: 106 mm
  • Height of sensor: 99 mm
  • Diameter of Castor: 25 mm
  • Length of the lever: 25 mm
  • Width of the lever: 25 mm
  • Height of the lever: 141 mm
  • Degree of protection: IP65
  • Ambient temperature: -30 ... +90 °C
  • Rated insulation voltage Ui: 400 V
  • Rated impulse withstand voltage Uimp: 6 kV
  • Thermal test current: 16 A
  • Utilisation category AC-15: 400 VAC
  • Utilisation category AC-15: 4 A
  • Switching element: NO contact, NC contact
  • Switching principle: Slow action
  • Maximum switching frequency: 3,000 /h
  • Material of the contacts, electrical: Silver
