DI-Soric BS-Z-8-UND, Signal processing, sku: 203682

Logic distributors can logically link several sensors together and feature a switchable AND/OR switching function. With their high protection class they can be easily retrofitted and exhibit a large range of temperatures in which they can be used.

• High protection type IP 67
• Compact design
• Metal thread
• Plastic housing

Current-carrying capacity	3000 mA (at 40°)
Service voltage	60 V DC
Housing material	Plastic / Metal
Protection class	III, operation on protective low voltage
Evaluation	AND/OR
Characteristics	Metal nut
To be used for	Logic distributor AV4 AND/OR
Switching output	Not available
Ambient temperature during operation	-30 … +80 °C
Protection type	IP 67 (at tightening torque 0.4 Nm)
Connection	Connector, M8, 3-pin
Connection 2	Not available
