DI-Soric CS60-UP-ID-LIZENZ

The upgrade licenses extend our vision sensors with additional functions such as measuring, reading 1D and 2D codes, and our fix-mounted ID readers with reading difficult-to-read DPM codes.

• The CS60-UP ID LICENSE adds the Localize and Detect ID Code functions to the sensor. Using the code, its x/y position can be used to track subsequent tools. Additionally, 1D and 2D codes are read.
• To activate the upgrade, the license file is simply transferred to the sensor using the nVision-i Start interface.

Model	Upgrade
To be used for	CS 60 Vision Sensors
Code type - 1D-Codes (barcodes)	Code 39, Code 128, Interleaved 2 of 5, Codabar, IATA 2 of 5, Hong Kong 2 of 5, Matrix 2 of 5, NEC 2 of 5, Pharmacode, Straight 2 of 5, GS1 Databar RSS 14, GS1 DataBar RSS 14 Stacked, GS1 Databar Limited, GS1 Databar Expanded, GS1 DataBar Expanded Stacked, UPC A, UPC E, EAN 8, EAN 13
Code type - 2D-Codes	Data Matrix, Aztec Code, PDF 417, PDF 417 Micro, QR 2005, QR Micro, QR Model 1
