Dold
Dold BC7931N.71 AC/DC24V+AC230V 0,05-1S, Fleeting action relay, sku: 0052662
Dold BC7931N.71 AC/DC24V+AC230V 0,05-1S, Fleeting action relay, sku: 0052662
Regular price
€59,58
Regular price
Sale price
€59,58
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 31.12.2025
Couldn't load pickup availability
SKU: SKU:0052662
Time-dependent controllers.
| Width: | 22,5 mm |
| Time function(s): | Fleeting on make |
| Nominal voltage: | AC, AC/DC |
| Time range: | 0,05 s - 100 s |
| Output contacts: | 1 C/O contact |
| Enclosure design: | Switch cabinet |
| Type: | BC 7931N |
- According to IEC/EN 61 812-1
- Fleeting action
- Repeat time adjustable to 100 s
- Repeat accuracy ≤ 0.5 % + 10 ms
- Dual voltage supply
- LED indicator for contact position
- 1 changeover contact
- Wire connection: also 2 x 1.5 mm2 stranded ferruled (isolated),
DIN 46 228-1/-2/-3/-4 or
2 x 2.5 mm2 stranded ferruled DIN 46 228-1/-2/-3 - Width 22.5 mm
