Dold
Dold IN8701.04/006 AC50HZ 230V, Input-Output interface relay, sku: 0045684
Dold IN8701.04/006 AC50HZ 230V, Input-Output interface relay, sku: 0045684
Regular price
€206,98
Regular price
Sale price
€206,98
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 31.12.2025
Couldn't load pickup availability
SKU: SKU:0045684
For switching lamp loadsInput interface relay, e.g. for activation of PLCOutput interface relay, e.g. for PLC-controlled loads
| Width: | 52,5 mm |
| Nominal voltage: | AC, DC |
| Initiator triggering: | Yes |
| Suppressor circuit on the coil input: | Yes |
| Thermal current Ith max.: | 16 A |
| Output contacts max.: | 4 C/O contacts |
| Enclosure design: | Distribution board |
| Type: | IN 8701 |
- According to EN 60947-5-1
- Pushbutton for manual actuation of the contact
- Operating position display
- High thermal current Ith
- Width: 17.5 or 35 or 52.5 mm
