IFM AC2619 - AS-Interface universal module UniversalModule 2AO(V) IP65

Easy to mount and wire.
For the connection of sensors and actuators with cable entry.
Device connection with cage clamps.
Clearly visible powerful LEDs for displaying operation, switching status and error

Application	field installation

Operating voltage [V]	26.5...31.6 DC
Max. current consumption from AS-i [mA]	140
Reverse polarity protection	yes
Additional voltage supply [V]	24...30 DC;(AUX)
Additional voltage supply	optional
Max. current consumption from additional supply [mA]	550;(AUX)

Inputs / outputs

Number of inputs and outputs	Number of analogue outputs: 2

Inputs

Precision analogue input [%]	0,5

Outputs

Number of analogue outputs	2;(connection of 2-wire or 4-wire actuators)
Analogue voltage output [V]	0...10
Min. load resistance [Ω]	3300
Overload protection	yes
Resolution of analogue output	16 (1 bit = 1 mV)
Actuator supply outputs	AS-i / AUX

Operating conditions

Ambient temperature [°C]	0...70
Storage temperature [°C]	-25...85
Max. relative air humidity [%]	90;(non condensing)
Max. height above sea level [m]	2000
Protection	IP 65

Tests / approvals

EMC	EN 50295
MTTF [years]	145

AS-i classification

AS-i master profile	M3; M4
AS-i profile	S-7.3.5
AS-i I/O configuration [hex]	7
AS-i ID code [hex]	3.5

Weight [g]	296.5
Type of mounting	AS-i interface to FC-E lower parts
Materials	PBT

Displays / operating elements

Display	analogue signal LED, yellow channels AO1...AO2 operation LED, green AS-i, AUX errors LED, red

Electrical connection

Module connection	Flat cables

Pack quantity	1 pcs.

Electrical connection

Connection	cage clamps:

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — AC2619-01 — 24.01.2024 —
