IFM AL1000 - IO-Link master with PROFINET interface IO-Link Master PL PN 8P IP67

Reliable transmission of machine data, process parameters and diagnostic data to the controller.
With integrated fieldbus interface.
Large operating temperature range and high protection rating.
Robust housing for use in harsh industrial environments

Application	I/O modules for field applications
Daisy-chain function	power supply; fieldbus interface

Operating voltage [V]	19...31.2 DC;(US)
Protection class	III
Additional voltage supply [V]	19...31.2 DC;(UA)

Current rating per port [A]	1.6

Current rating per port [A]	0.2

Inputs / outputs

Total number of inputs and outputs	12;(configurable)
Number of inputs and outputs	Number of digital inputs: 12; Number of digital outputs: 8

Inputs

Number of digital inputs	12;(IO-Link Port Class A: 4 x 2; IO-Link Port Class B: 4 x 1)
Switching level high [V]	15...30
Switching level low [V]	-3...5
Digital inputs protected against short circuits	yes

Outputs

Number of digital outputs	8;(IO-Link Port Class A: 4 x 1; IO-Link Port Class B: 4 x 1)
Max. current load per output [mA]	200
Short-circuit proof	yes
Actuator supply outputs	24 V DC

Interfaces

Communication interface	Ethernet; IO-Link

Protocol	PROFINET

Transmission type	COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud)
IO-Link revision	1.1
Number of ports class A	4
Number of ports class B	4

Operating conditions

Ambient temperature [°C]	-25...60
Storage temperature [°C]	-25...85
Max. relative air humidity [%]	95
Protection	IP 65; IP 67

Tests / approvals

EMC	EN 61000-6-2 EN 61000-4-2 ESD 6 kV contact discharge / 8 kV air discharge EN 61000-4-3 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6
Shock resistance	EN 60068-2-27 30 g 11 ms
Vibration resistance	EN 60068-2-6 5 g

Weight [g]	574
Materials	housing: PA; socket: brass nickel-plated
Sealing material	FKM

Remarks	For further information please see the operating instructions.
Pack quantity	1 pcs.

Electrical connection - Ethernet

IN / OUT X21, X22	Connector:M12; coding: D; Sealing: FKM

Electrical connection - Process connection

IO-Link Port Class A X01...X04	Connector:M12; coding: A; Sealing: FKM

Electrical connection - power supply IN

X31	Connector:M12; coding: T

Electrical connection - power supply OUT

X32	Connector:M12; coding: T; Sealing: FKM
