IFM CR2011 - I/O module for mobile machines R360/COMPACT-MODULE/O/8

Decentralised connection of sensors and actuators.
With many multifunctional configurable input and output channels.
High-performance CAN interface for various communication tasks.
High protection rating for the requirements of mobile machines

Operating voltage [V]	10...32 DC

Inputs / outputs

Total number of inputs and outputs	8
Number of inputs and outputs	Number of digital outputs: 8

Outputs

Number of digital outputs	8
Number of PWM outputs	8

Interfaces

Number of CAN interfaces	1

Tests / approvals

MTTF [years]	268

Weight [g]	483.8
Dimensions [mm]	152 x 60 x 22

Pack quantity	1 pcs.

Electrical connection

	Connector: 1 x M12

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — CR2011-02 — 12.12.2012 —
