IFM CR2013 - I/O module for mobile machines R360/COMPACT-MODULE/I/8/O/4

Decentralised connection of sensors and actuators.
With many multifunctional configurable input and output channels.
High-performance CAN interface for various communication tasks.
High protection rating for the requirements of mobile machines

Operating voltage [V]	10...32 DC

Inputs / outputs

Total number of inputs and outputs	8
Number of inputs and outputs	Number of digital inputs: 4; Number of analogue inputs: 4; Number of digital outputs: 4

Inputs

Number of digital inputs	4
Number of analogue inputs	4
Analogue input (voltage) [V]	0...10

Outputs

Number of digital outputs	4
Number of PWM outputs	4

Software / programming

Parameter setting options	input/output functions

Interfaces

Number of CAN interfaces	1

Tests / approvals

MTTF [years]	253

Weight [g]	479.8
Dimensions [mm]	152 x 60 x 22

Pack quantity	1 pcs.

Electrical connection

	Connector: 1 x M12

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — CR2013-02 — 12.12.2012 —
