USA; Canada; EU/RED; Australia; Japan; Taiwan; India; China; Israel
Note on radio approval
The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”.
Operating voltage [V]
9...32 DC
Current consumption [mA]
< 150;(24 V)
Protection class
III
Operating frequency [MHz]
13,56
Detection zone
Distance write/read head front [mm]
900
Distance write/read head side [mm]
1200
Distance to the ID tag [mm]
referred to the ID tag E80384
:
< 190
Interfaces
Communication interface
CAN
Protocol
CANopen
Operating conditions
Ambient temperature [°C]
-20...60
Storage temperature [°C]
-25...80
Protection
IP 67
Tests / approvals
Shock resistance
EN 60068-2-27
40 g 6 ms / bump
EN 60068-2-27
50 g 11 ms / single shock
Vibration resistance
EN 60068-2-6
2 g 10...150 Hz
Weight [g]
458.5
Dimensions [mm]
120 x 50 x 113
Materials
PBT; PC; stainless steel
Displays / operating elements
Display
operation
1 x LED, green/red CANopen interface
1 x LED bar display, yellow tag communication
Remarks
For the distances to other ID tags see the respective data sheet (E803xx)
Pack quantity
1 pcs.
Electrical connection - plug
Connector: 1 x M12; coding: A
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — DTC600-00 — 06.10.2023 —
