USA; Canada; South Korea; Japan; Taiwan; Singapore; Malaysia; China; EU/RED; India
Note on radio approval
The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”.
Operating voltage [V]
19.2...28.8 DC
Current consumption [mA]
500
Protection class
III
Operating frequency [MHz]
13,56
RFID standard
ISO 15693
Outputs
Max. current load per output [mA]
100;(max.)
Detection zone
Distance write/read head front [mm]
600
Distance write/read head side [mm]
850
Note on distance write/read head
100%
transmission power
Distance to the ID tag [mm]
50 mm tag
:
≤ 150
ISO card
:
≤ 180
Interfaces
Communication interface
Ethernet
Ethernet - Internet of Things
Transmission standard
10Base-T; 100Base-TX
Transmission rate
10 MBit/s; 100 MBit/s
Protocol
MQTT JSON
Factory settings
IP address: 192.168.0.79
subnet mask: 255.255.255.0
gateway IP address: 192.168.0.100
Usage type
parameter setting; data transmission
Operating conditions
Ambient temperature [°C]
-20...60
Storage temperature [°C]
-25...80
Protection
IP 67
Tests / approvals
Shock resistance
IEC 60028-2-27
40 g (6 ms) / bump
50 g (11 ms) / single shock
Vibration resistance
EN 60068-2-6
2 g (10...150 Hz)
UL approval
Ta
-20…60 °C
Enclosure type
Type 1
power supply
Limited Voltage/Current
File number UL
E205959
Weight [g]
645.1
Dimensions [mm]
113 x 118.5 x 50
Materials
PBT / PC; stainless steel; aluminium
Displays / operating elements
Display
power supply
1 x LED, green
LED bar display
4 x LED, yellow signal strength ID tag
status
2 x LED, green/red fieldbus interface
status
2 x LED, green/yellow Ethernet
Pack quantity
1 pcs.
Electrical connection - Ethernet
ETH1 / ETH2
Connector: 2 x M12; coding: D
Electrical connection - power supply
PWR
Connector: 1 x M12; coding: A
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — DTE605-00 — 06.10.2023 —
