The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”.
Operating voltage [V]
19.2...28.8 DC
Current consumption [mA]
500
Power consumption [W]
8.6
Protection class
III
Operating frequency [MHz]
865...868 (ETSI)
RFID standard
EPC Class1 GEN2/ISO 18000-63
Transmission power ERP [mW]
120;(maximum: 200 mW)
Outputs
Max. current load per output [mA]
100;(max.)
Interfaces
Communication interface
Ethernet
Ethernet - TCP/IP
Protocol
TCP/IP
Factory settings
IP address: 192.168.0.79
subnet mask: 255.255.255.0
gateway IP address: 192.168.0.100
Usage type
parameter setting
Operating conditions
Ambient temperature [°C]
-20...55
Note on ambient temperature
with mounting plate and cooling element: -20...60 °C
Storage temperature [°C]
-25...80
Protection
IP 67
Tests / approvals
Shock resistance
IEC 60028-2-27
40 g (6 ms) / bump
50 g (11 ms) / single shock
Vibration resistance
EN 60068-2-6
2 g (10...150 Hz)
MTTF [years]
58
Weight [g]
701.7
Dimensions [mm]
113 x 118.6 x 50
Materials
housing: aluminium; PBT / PC; stainless steel
Displays / operating elements
Display
power supply
1 x LED, green
LED bar display
4 x LED, yellow number of tags in the field
status
2 x LED, green/red fieldbus interface
status
2 x LED, green/yellow Ethernet
Pack quantity
1 pcs.
Electrical connection - Ethernet
ETH1 / ETH2
Connector: 2 x M12; coding: D
Electrical connection - power supply
PWR
Connector: 1 x M12; coding: A
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — DTE804-01 — 09.10.2023 —
