IFM E11847 - Splitter box ProcessLine SB V4A 25m

Specially for the use in wet areas of the food and beverage industry.
Hygienic design without corners and edges.
Resistant to high-pressure cleaning with aggressive cleaning agents.
Clearly visible powerful LEDs for displaying operation, switching status and error.
Large number of slots

Operating voltage [V]	10...36 DC
Protection class	III
Max. current load per module/slot [A]	4
Max. current load total [A]	6

Outputs

Electrical design	PNP

Operating conditions

Ambient temperature [°C]	-5...70
Protection	IP 69K;(To ensure the protection rating unused sockets must be covered with the supplied protective caps.; Tightening torque: 1,3 Nm +/- 0,1 Nm)

Tests / approvals

MTTF [years]	2487

Weight [g]	5376
Dimensions [mm]	Ø 137.3 / L = 72
Materials	threaded bush: stainless steel (1.4404 / 316L); LED-Fenster: PC; O-ring: EPDM; Protective cap: PP
Moulded-body material	stainless steel
Number of ports splitter box	8
Connector type	M12

Displays / operating elements

Display	switching status 16 x LED, yellow operation 1 x LED, green

Accessories

Items supplied	Protective caps: M12

Remarks	external voltage supply according to PELV
Pack quantity	1 pcs.

Electrical connection

	Cable: 25 m, PUR / PVC, black, Ø 11 mm; 3 x 0.75 mm² + 16 x 0.34 mm²

Electrical connection - slot

Connection	Connector: 8 x M12; coding: A; Moulded body: stainless steel
