IFM E30010 - Screw-in adapter for process sensors ADAPT PX G1/4A-M20X1,5A

For the installation of pressure sensors in containers and pipes.
Easy, quick and secure mounting.
Use in industrial and mobile hydraulics.
High pressure rating.
Stable fixing by screwing in

Pressure rating [bar]	200

Tests / approvals

Pressure Equipment Directive	A possible classification to PED depends on the application and has to be carried out by the user / operator.
Safety instructions	The compatibility between medium andproduct material has to be checked in all applications.

Weight [g]	78.7
Dimensions [mm]	M20
Thread designation	M20
Materials	stainless steel (1.4305 / 303); FKM
Sensor connection	G 1/4
Process connection	threaded connection M20 x 1,5

Pack quantity	1 pcs.

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E30010-00 — 26.06.2013 —
