RFID tag 125 kHz - Q5. Reliable coding of workpiece carriers. Suitable for installation with plastic carrier
Application
coding of workpiece carriers in routing conveyors
Operating temperature (active) [°C]
-40...85
Peak temperature (passive) [°C]
120;(duration of test: 1 x 100 h)
Operating frequency [MHz]
0,125
Memory size [bit]
224
Max. read cycles
unlimited
Max. write cycles
100000
Operating conditions
Ambient temperature [°C]
-40...85
Storage temperature [°C]
-40...90
Protection
IP 67
Tests / approvals
Shock resistance
DIN IEC 68-2-29
30 g 18 ms
Vibration resistance
DIN IEC 68-2-6
6 g 14...200 Hz
MTTF [years]
2854
Weight [g]
1.9
Housing
threaded type
Type of mounting
screw mounting
Dimensions [mm]
M5 x 0.8 / L = 16.5
Thread designation
M5 x 0.8
Materials
PA black
Remarks
peak temperature 1 x 100 h
Storage temperature 1 x 1000 h
shock 3 Achsen je 1084 Schocks
vibration 3 Achsen je 8 h
Pack quantity
1 pcs.
Other data
read/write distance (mm)
positioning of the ID tag
read
write
DTA100
front side
20
10
DTA101
front side
20
–
All indications apply to static read/write operations.
Indications without comment refer to the installation of ID tags in non-metallic environments.
