IFM EVC02E - PNP/NPN inverter module Converter PNP-NPN SIGNAL PIN 2

Reliable signal conversion from PNP to NPN.
For sensors with normally closed function.
Resistant to oils and coolants.
High protection rating for the requirements of harsh industrial environments.
Vibration and shock resistant thanks to coupling ring with locking mechanism

Special feature	Halogen-free; Gold-plated contacts; Drag chain suitability
Compatible with paint	yes

Operating voltage tolerance [%]	10
Operating voltage [V]	< 24 DC
Protection class	II
Max. current load total [A]	0.1

Outputs

Max. voltage drop switching output DC [V]	2

Operating conditions

Ambient temperature [°C]	-25...60
Ambient temperature (moving) [°C]	-25...60
Protection	IP 65; IP 67; IP 68; IP 69K

Weight [g]	179
Dimensions [mm]	26.5 x 15.5 x 36.5
Materials	housing: TPU black; Sealing: FKM
Material nut	brass, nickel-plated
Drag chain suitability	yes
Drag chain suitability	bending radius for flexible use min. 10 x cable diameter travel speed max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s² bending cycles > 5 Mio. torsional strain ± 180 °/m

Remarks	for sensors to IEC 60947-5-2 with normally closed operation
Notes	Please see the technical note under "Downloads"
Pack quantity	1 pcs.

Electrical connection

	Cable: 5 m, PUR, Halogen-free, black, Ø 4.3 mm; 4 x 0.34 mm² (42 x Ø 0.1 mm )

Electrical connection - socket

Connection	Connector: 1 x M12, angled; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.6...1.5 Nm

ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — EVC02E-01 — 10.01.2020 —
