For use in hygienic and wet areas in the food industry. Permanent, reliable sealing even when mounted without tools. Large operating temperature range and high protection rating. Vibration and shock resistant thanks to coupling ring with locking mechanism. Mechanical end stop to protect the O-ring from destruction
Special feature
Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability
Application
hygienic and wet areas in the food industry
Free from silicone
yes
Operating voltage [V]
< 50 AC / < 60 DC;(cULus: 30 AC / 30 DC)
Protection class
III
Max. current load total [A]
3
Operating conditions
Ambient temperature [°C]
-25...80
Ambient temperature (moving) [°C]
5...80
Protection
IP 65; IP 67; IP 68; IP 69K
Tests / approvals
UL approval
power supply
Class 2
Weight [g]
288.9
Dimensions [mm]
19 x 10 x 25.5
Materials
housing: PP grey; Sealing: EPDM
Material nut
stainless steel (1.4404 / 316L)
Drag chain suitability
yes
Drag chain suitability
bending radius for flexible use
min. 10 x cable diameter
travel speed
max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s²
bending cycles
> 1 Mio.
torsional strain
± 180 °/m
Pack quantity
1 pcs.
Electrical connection
Cable: 10 m, MPPE, Halogen-free, grey, Ø 4.9 mm; 3 x 0.34 mm² (42 x Ø 0.1 mm )
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — EVF128-00 — 04.11.2022 —
