Connection technology meets the M12 and M8 standard (EN 61076). Vibration and shock resistant thanks to coupling ring with locking mechanism. Mechanical end stop to protect the O-ring from destruction. Excellent price/performance ratio. LEDs clearly visible even under bright lighting
Special feature
Free from silicone; Gold-plated contacts; Drag chain suitability
Free from silicone
yes
Operating voltage [V]
10...36 DC
Protection class
II
Max. current load total [A]
4
Outputs
Electrical design
PNP
Operating conditions
Ambient temperature [°C]
-25...70
Ambient temperature (moving) [°C]
5...70
Protection
IP 65; IP 67
Weight [g]
327.2
Dimensions [mm]
26.5 x 15.5 x 36.5
Materials
housing: TPU black transparent; Sealing: FKM
Material nut
brass, nickel-plated
Drag chain suitability
yes
Drag chain suitability
bending radius for flexible use
min. 10 x cable diameter
travel speed
max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s²
bending cycles
1 Mio.
torsional strain
± 180 °/m
Displays / operating elements
Display
switching status
1 x LED, yellow
operation
1 x LED, green
Pack quantity
1 pcs.
Electrical connection
Cable: 10 m, PVC, black, Ø 4.5 mm; 3 x 0.25 mm² (14 x Ø 0.15 mm )
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — EVS009-00 — 05.11.2020 —
