Permanent current rating of switching output DC [mA]
100
Switching frequency DC [Hz]
> 1000
Short-circuit protection
yes
Type of short-circuit protection
pulsed
Overload protection
yes
Detection zone
Response sensitivity [mT]
2.8
Accuracy / deviations
Hysteresis [mm]
0.5...1.5
Repeatability [mm]
< 0.1
Operating conditions
Ambient temperature [°C]
-25...80
Protection
IP 65; IP 67; IP 68
Tests / approvals
EMC
EN 61000-4-2
- CD / 8 kV AD
EN 61000-4-3
10 V/m
EN 61000-4-4
2 kV
EN 61000-4-6
10 V
EN 55011
class B
Vibration resistance
DIN EN 60068-2-6
15 g (10...55 Hz) / 10 frequency cycles, 1 octave/minute, in 3 axes
Shock resistance
DIN IEC 68-2-27
30 g 11 ms Halbsinus; je 1000 Schocks in jede Richtung der 3 Koordinatenachsen
Vibration resistance
DIN EN 60068-2-64
10 g / (20...2000 Hz) 100 Minuten, in 3 Achsen
MTTF [years]
3523
UL approval
Ta
-25...55 °C
Enclosure type
Type 1
power supply
Class 2
UL Approval no.
C013
File number UL
E174191
Weight [g]
63.15
Mounting
flush mountable
Cylinder type
C-slot cylinders
Dimensions [mm]
32 x 6.4 x 5.1
Materials
housing: PA glass fibre reinforced; threaded sleeve: brass; set screw: stainless steel
Displays / operating elements
Display
switching status
1 x LED, yellow
Pack quantity
1 pcs.
Electrical connection
Connection
Cable: 5 m, PUR; 3 x 0.14 mm²
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — MK5532-00 — 19.01.2024 —
