8;(with reduced measuring accuracy and repeatability: < 100)
Tests / approvals
EMC
DIN EN 61000-6-4
radiation of interference / industrial environments
DIN EN 61000-6-2
immunity / industrial environments
Shock resistance
DIN EN 60068-2-27
50 g / (11 ms) not repetitive
DIN EN 60068-2-27
40 g / (6 ms) repetitive
Vibration resistance
DIN EN 60068-2-6
2 g / (10...150 Hz)
DIN EN 60068-2-64
2.3 g RMS / (10...500 Hz)
Photobiological safety
exempt group;(DIN EN 62471)
Electrical protection
DIN EN 61010-2-201
electrical supply only via PELV circuits
Weight [g]
768.9
Dimensions [mm]
72 x 67.1 x 82.6
Materials
housing: diecast aluminium; front pane: Gorilla Glass; function display: PA
Displays / operating elements
Display
function
2 x LED, green Ethernet operation
switching status
2 x LED, yellow OUT 1 OUT 2
Accessories
Items supplied
spring washers
Pack quantity
1 pcs.
Electrical connection - Ethernet
Connector: 1 x M12; coding: D
Electrical connection - Process connection
Connector: 1 x M12; coding: A
Other data
Field of view size
measuring range / distance [m]
Length [m]
Width [m]
0.50
0.26
0.35
1.00
0.52
0.69
2.00
1.04
1.39
3.00
1.56
2.08
4.00
2.08
2.78
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — O3DP21-00 — 05.11.2020 —
