Rittal
Rittal AS 4050.456, Crimping machine RC
Rittal AS 4050.456, Crimping machine RC
Regular price
€20.067,86
Regular price
Sale price
€20.067,86
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 07.12.2025
Couldn't load pickup availability
SKU: SKU:AS 4050.456
Electropneumatic crimping machine with 5-way magazine for processing insulated wire end ferrules in various cross-sections on a reel.
| Article number: | AS 4050.456 |
| Design | Touchscreen displaySelect the wire cross-section via touchscreenSupport may be fitted with a maximum of 23,000 wire end ferrules |
| Product description | |
| Benefits | Easy to operate |
| Technical specifications | Crimping range 0.5 - 2.5 mm² (AWG 20 - 14) |
| Note | The standard crimping form is trapezoid – others available on request |
| Dimensions | Width: 335 mmHeight: 565 mmDepth: 485 mm |
| Compressed air connection | 5.5 bar |
| Rated operating voltage | 100 V - 240 V, 1~, 50 Hz/60 Hz |
| Apparent power | 16 VA |
| Compression | Trapezoid crimp |
| Cycle time | < 2 s |
| Packs of | 1 pc(s). |
| Net weight | 24.8 kg |
| Gross weight | 25.4 kg |
| Customs tariff number | 84624900 |
| EAN | 4028177930865 |
| ETIM 9 | EC002778 |
| ETIM 8 | EC002778 |
| ECLASS 8.0 | 17130101 |
| Product description | RC crimping machine, insulation stripping and crimping, for processing 5 wire end ferrules |
