Rittal DK 5302.044, Cable clamp rail, depth-variable for VX IT, TE
Rittal DK 5302.044, Cable clamp rail, depth-variable for VX IT, TE
Regular price
€49,62
Regular price
Sale price
€49,62
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 04.12.2025
Couldn't load pickup availability
SKU: SKU:DK 5302.044
For VX IT and TE. Allows their length to be flexibly adapted to the existing mounting distance between the two 482.6 mm (19") mounting levels.
| Article number: | DK 5302.044 |
| Benefits | The depth variability of the rails allows their length to be flexibly adapted to the given mounting distance between the two 482.6 mm (19") mounting levels. |
| Applications | For cable routing on the enclosure frame and for strain relief of the routed cables. The cables can be attached to the cable clamp rails with cable ties or velcro fasteners. |
| Material | Sheet steel |
| Surface finish | Zinc-plated |
| Supply includes | Assembly parts |
| Distance between levels | 350 ‐ 550 mm |
| Note | Mounting dimensions + 170 mm = distance between 482.6 mm (19") levels for VX IT, standard |
| Packs of | 1 pc(s). |
| Net weight | 0.67 kg |
| Gross weight | 0.687 kg |
| PCF per pack (cradle-to-gate) | 2.6 kg CO2 eq (Cat B) |
| Note on PCF category | Category B: PCF value (cradle-to-gate) based on the product weight, approximately calculated and self-declared |
| Customs tariff number | 73269098 |
| EAN | 4028177952690 |
| ETIM 9 | EC000322 |
| ECLASS 8.0 | 27400604 |
| Product description | Cable clamp rail, depth-adjustable for VX IT, TE, for cable routing on the enclosure frame and for strain relief of the routed cables. The cables can be attached to the cable clamp rails with cable ties or velcro fasteners. |
