Rittal
Rittal DK 7000.630, Socket strip in a plastic housing
Rittal DK 7000.630, Socket strip in a plastic housing
Regular price
€53,76
Regular price
Sale price
€53,76
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 04.12.2025
Couldn't load pickup availability
SKU: SKU:DK 7000.630
Socket strips 230 V, unrestricted use, including angular connectors, thanks to the long row arrangement of plug-type contacts.
| Article number: | DK 7000.630 |
| Product description | 8-way socket strip for earthing-pin plug (type F, CEE 7/4) The strip may be mounted vertically on the enclosure frame or in the rear 482.6 mm (19") section. In the 482.6 mm (19") section, more than 2 U of space is required. The sockets are arranged at an angle of 45° so that angular connectors are also easily used. The connection cable is contacted in a terminal slot in the strip. The terminal slot has a separate cover and external terminals for separate earthing. |
| Material | Plastic |
| Supply includes | Connection cableAssembly screws2 serrated washersCaptive nuts M6, conductiveNuts |
| Design | Without switch |
| Sockets | 8 x D, earthing-pin (type F, CEE 7/3) |
| Length of connection cable | 2 m |
| Connection cable (type) | H05VV-F3G1.5 with wire end ferrules |
| Rated operating voltage | 230 V AC, 50 Hz |
| Rated voltage | 230 V AC, 50 Hz |
| Rated current (max.) | 16 A |
| Type of electrical connection | Wire end ferrules |
| Installation options | TE 7000, rear 482.6 mm (19") section (> 2 U) |
| Colour of socket | Black |
| Packs of | 1 pc(s). |
| Net weight | 0.92 kg |
| Gross weight | 1.026 kg |
| Customs tariff number | 85366990 |
| EAN | 4028177438569 |
| ETIM 9 | EC000330 |
| ECLASS 8.0 | 27142604 |
| Product description | DK-TS Socket strip, CEE 7/3 (type F), 8-way, 230 V, 16 A, LHD: |
