Rittal SV 9342.570, Connection bracket for circuit-breaker component adaptors
Rittal SV 9342.570, Connection bracket for circuit-breaker component adaptors
Regular price
€20,71
Regular price
Sale price
€20,71
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 08.12.2025
Couldn't load pickup availability
SKU: SKU:SV 9342.570
Pre-assembled, laminated flat copper for connecting standard, commercially available circuit-breakers.
| Article number: | SV 9342.570 |
| Product description | Pre-assembled, laminated flat copper for connecting standard, commercially available moulded case circuit-breakers (MCCB). |
| Material | Electrolytic copper F20 |
| Note | Universal application for switchgear with a dimensional difference between the mounting level and the upper edge of the contact level of 20 ± 5 mm. |
| To fit Model No. | 9342.500 |
| Version – laminated flat copper | Number of lamina: 6Membrane width: 9 mmMembrane thickness: 0.8 mm |
| To fit manufacturer (model) | ABB (T1, T1 UL, T2, T2 UL) |
| Packs of | 3 pc(s). |
| Net weight | 0.096 kg |
| Gross weight | 0.103 kg |
| Copper weight (kg per piece) | 0.032 |
| Customs tariff number | 73182900 |
| EAN | 4028177551947 |
| ETIM 9 | EC002270 |
| ECLASS 8.0 | 27409221 |
| Product description | SV Connection bracket E-Cu, for circuit-breaker component adaptor, SV 9342500/510/540/550 |
