Rittal
Rittal SV 9629.000, Mini-PLS component adaptor
Rittal SV 9629.000, Mini-PLS component adaptor
Regular price
€49,47
Regular price
Sale price
€49,47
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 08.12.2025
Couldn't load pickup availability
SKU: SKU:SV 9629.000
Maximum rated current from 12 A to 100 A.
| Article number: | SV 9629.000 |
| Material | PolyamideFire protection corresponding to UL 94-V0 |
| Colour | RAL 9011 |
| Connection cables (AWG) | 35 mm² |
| Rated operating voltage | 690 V, 3~ |
| Rated current max. | 100 A |
| Dimensions | Width: 90 mmHeight: 160 mm |
| To fit manufacturer (model) | ABBEatonSchneider ElectricSiemensMS451 max. 40 AMS495MS496MS497T1T2NZM 1PKZM4NS 80GV33RV10 313RV1341/42 |
| Packs of | 1 pc(s). |
| Net weight | 0.694 kg |
| Gross weight | 0.759 kg |
| Copper weight (kg per piece) | 0.23 |
| Customs tariff number | 85369095 |
| EAN | 4028177149861 |
| ETIM 9 | EC001531 |
| ECLASS 8.0 | 27370304 |
| Product description | SV Mini-PLS component adaptor, 100 A, 690 V, 3-pole, connection cable 35 mm², WH: 90x160 mm |
