Rittal SZ 2561.100, Metal gland plate with metric knockouts
Rittal SZ 2561.100, Metal gland plate with metric knockouts
Regular price
€23,91
Regular price
Sale price
€23,91
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 04.12.2025
Couldn't load pickup availability
SKU: SKU:SZ 2561.100
Simply knock out the holes for the cable glands using a screwdriver, IP 66 when mounting in the usual position at the bottom.
| Article number: | SZ 2561.100 |
| Product description | Simply knock out the holes for the cable glands using a screwdriver. |
| Material | Sheet steel |
| Colour | RAL 7035 |
| Note | The allocation of gland plate sizes is indicated on the relevant enclosures |
| No. of metric knockouts | 9 x M204 x M252 x M32 |
| Dimensions | Width: 330 mmDepth: 90 mm |
| To fit | Enclosure type: AE |
| Gland plate | Size: 3 |
| Protection category to IEC 60 529 | IP 66 when mounting in the usual position at the bottom |
| Number knockouts | 942 |
| Metric diameter | M20 |
| Packs of | 1 pc(s). |
| Net weight | 0.31 kg |
| Gross weight | 0.356 kg |
| Customs tariff number | 73269098 |
| EAN | 4028177390850 |
| ETIM 9 | EC000211 |
| ETIM 8 | EC000211 |
| ECLASS 8.0 | 27142421 |
| Product description | SZ Metal gland plate, with metric knock-outs, WD: 330x90 mm, size: 3 |
