Rittal SZ 2563.100, Metal gland plate with metric knockouts
Rittal SZ 2563.100, Metal gland plate with metric knockouts
Regular price
€30,77
Regular price
Sale price
€30,77
Unit price
/
per
Taxes included.
📦 Ready for dispatch: 04.12.2025
Couldn't load pickup availability
SKU: SKU:SZ 2563.100
Simply knock out the holes for the cable glands using a screwdriver, IP 66 when mounting in the usual position at the bottom.
| Article number: | SZ 2563.100 |
| Product description | Simply knock out the holes for the cable glands using a screwdriver. |
| Material | Sheet steel |
| Colour | RAL 7035 |
| Note | The allocation of gland plate sizes is indicated on the relevant enclosures |
| No. of metric knockouts | 1 x M1212 x M2011 x M258 x M324 x M40 |
| Dimensions | Width: 534 mmDepth: 149 mm |
| To fit | Enclosure type: AE |
| Gland plate | Size: 5 |
| Protection category to IEC 60 529 | IP 66 when mounting in the usual position at the bottom |
| Number knockouts | 1121184 |
| Metric diameter | M12 |
| Packs of | 1 pc(s). |
| Net weight | 0.96 kg |
| Gross weight | 1.004 kg |
| Customs tariff number | 73269098 |
| EAN | 4028177390874 |
| ETIM 9 | EC000211 |
| ETIM 8 | EC000211 |
| ECLASS 8.0 | 27142421 |
| Product description | SZ Metal gland plate, with metric knock-outs, WD: 534x149 mm, size: 5 |
