Schmersal CSS 12-34-V-SD-M-ST Sicherheits-Sensoren, sku: 101181067

Schmersal CSS 12-34-V-SD-M-ST Sicherheits-Sensoren, sku: 101181067

€10.000,00
€10.000,00
Sale Sold out
Taxes included.

📦 Ready for dispatch: 07.03.2026

SKU: 101181067

  • 1 x Einbaustecker M12, 8-polig
  • kopfseitige Betätigung
  • serieller Diagnoseausgang
  • Es können maximal 31 Sensoren in Reihe geschaltet werden.
  • Kunststoffgehäuse
  • berührungsloses, codiertes elektronisches System
  • versetzt anfahrbar
  • 27 mm x 108,2 mm x 35 mm
  • große Wiederholgenauigkeit der Schaltpunkte
  • max. Länge der Sensorkette 200 m
  • 2 plusschaltende, kurzschlussfeste Sicherheitsausgänge
  • integrierte Querschluss-, Drahtbruch-, Fremdspannungsüberwachung der Sicherheitsleitungen bis in den Schaltschrank
  • Product type description: CSS 12-34-V-SD-M-ST
  • Article number (order number): 101181067
  • EAN (European Article Number): 4030661314907
  • eCl@ss number, version 11.0: 27-27-24-03
  • eCl@ss number, version 9.0: 27-27-24-03
  • ETIM number, version 7.0: EC000030
  • ETIM number, version 6.0: EC000030
  • Certificates: TÜV, cULus, UKCA
  • Standards: EN IEC 60947-5-3
  • Working principle: inductive
  • Housing construction form: Block
  • Installation conditions (mechanical): not flush
  • Sensor topology: Sensor for series wiring
  • Enclosure material: Glass-fibre, reinforced thermoplastic
  • Active area: Glass-fibre, reinforced thermoplastic
  • Gross weight: 140 g
  • Reaction time, maximum: 30 ms
  • Duration of risk, maximum: 60 ms
  • Serial diagnostics: Yes
  • Diagnostic output: Yes
  • Short circuit detection: Yes
  • Cross-circuit detection: Yes
  • Safety functions: Yes
  • Cascadable: Yes
  • Integral system diagnostics, status: Yes
  • Number of LEDs: 3
  • Number of semi-conductor outputs with signaling function: 1
  • Number of fail-safe digital outputs: 2
  • Number of series-wiring of sensors: 31
  • Safety classification: 31
  • Standards: EN ISO 13849-1, EN IEC 60947-5-3, EN IEC 61508
  • Performance Level, up to: e
  • Category: 4
  • PFH value: 3.60 x 10⁻⁹ /h
  • Safety Integrity Level (SIL), suitable for applications in: 3
  • Mission time: 20 Year(s)
  • Actuating panels: Actuation from top
  • Active area: front side
  • Switching distance actuator: Actuator CST 180-1 / CST 180-2: 10 mm, Actuator CST 180-1 / CST 180-2: 12 mm, Actuator CST 180-1 / CST 180-2: 16 mm, Actuator CST 34-S-2: 10 mm, Actuator CST 34-S-2: 16 mm, Actuator CST 34-S-2: 8 mm, Actuator CST 34-S-3: 13 mm, Actuator CST 34-S-3: 15 mm, Actuator CST 34-S-3: 18 mm, Actuator CST 34-V-1: 10 mm, Actuator CST 34-V-1: 12 mm, Actuator CST 34-V-1: 15 mm
  • Hysteresis (Switching distance), maximum: 1.5 mm
  • Repeat accuracy R: 0.5 mm
  • Note (Repeat accuracy R): Axial offset: the front face allows for an axial misalignment (z) of max. ± 8 mm (see figure: operating principle).
  • Nominal switching distance Sn: 10 mm, 12 mm, 15 mm
  • Assured switching distance "ON" Sao: 10 mm, 13 mm, 8 mm
  • Assured switching distance "OFF" Sar: 15 mm, 16 mm, 18 mm
  • Termination: Connector plug M12, 8-pole
  • Note (length of the sensor chain): Cable length and cross-section change the voltage drop dependiing on the output current
  • Note (series-wiring): Unlimited number of devices, oberserve external line fusing, max. 31 devices in case of serial diagnostic SD
  • Length of sensor: 35 mm
  • Width of sensor: 27 mm
  • Height of sensor: 108.2 mm
  • Degree of protection: IP65, IP67
  • Ambient temperature: -25 ... +70 °C
  • Storage and transport temperature, minimum: -25 °C
  • Storage and transport temperature, maximum: +85 °C
  • Resistance to vibrations: 10 … 55 Hz, amplitude 1 mm
  • Restistance to shock: 30 g / 11 ms
  • Protection class: II
  • Rated insulation voltage Ui: 32 VDC
  • Rated impulse withstand voltage Uimp: 0.8 kV
  • Overvoltage category: III
  • Degree of pollution: 3
  • No-load supply current I0, maximum: 100 mA
  • Operating current: 600 mA
  • Required rated short-circuit current: 100 A
  • Note (Electrical data, Fuse rating): (Circuit breaker)
  • Switching frequency, approx.: 3 Hz
  • Rated operating current (safety outputs): 250 mA
  • Output current, (fail-safe output), maximum: 0.25 A
  • Design of control elements: p-type
  • Voltage drop Ud, maximum: 0.5 V
  • Leakage current Ir, maximum: 0.5 mA
  • Voltage, Utilisation category DC-12: 24 VDC
  • Current, Utilisation category DC-12: 0.25 A
  • Voltage, Utilisation category DC-13: 24 VDC
  • Current, Utilisation category DC-13: 0.25 A
  • Design of control elements: p-type
  • Voltage drop Ud, maximum: 5 V
  • Designation, Serial diagnostic SD: OUT
  • Operation current: 150 mA
  • Design of control elements: short-circuit proof, p-type
  • Wiring capacitance: 50 nF
  • Interfering radiation: IEC 61000-6-4
  • EMC rating: IEC 61000-6-2
  • PIN 1: 1A1 Ue: (1)
  • PIN 2: X1 Safety input 1
  • PIN 3: A2 GND
  • PIN 4: Y1 Safety output 1
  • PIN 5: SD serial diagnostic output
  • PIN 6: X2 Safety input 2
  • PIN 7: Y2 Safety output 2
  • PIN 8: IN serial diagnostic input
  • Scope of delivery: Actuator must be ordered separately.
  • Recommendation (actuator): CST 34-V-1, CST 34-S-2, CST 34-S-3, CST 180-1, CST 180-2
  • Recommended safety switchgear: PROTECT PSC1, SRB-E-301ST, SRB-E-201LC
  • Note (General): Evaluation requirements: dual-channel safety input, suitable for p-type sensors with NO function. The safety-monitoring module must tolerate internal functional tests of the sensors with cyclic switch-off of the sensor outputs for max. 0.5 ms. Short-circuit recognition by the evaluation is not necessary.
